Super silent
Bigger power
Easy for transportation
Maintenance made simpler
Stronger power
High-efficient combustion system ensures sufficient combustion;
muffler reduces exhaust noise greatly; engine noise is isolated in double structure and absorbed by special lining.
Wide application and wide range capacity can meet all requirements of clients.
Output the power you need
Strong, flexible, general, reliable and durable. You can find the most suitable generator here.
Control panel
All operation functions of the generator set are on the control panel, with a digital readable display showing operation time, output voltage and current. Breakers can protect generator set from overload damage.
Easy portable
An open frame configuration means it's easy to handle and store when not in use.
Wide application
Various models are avaliable to meet all customers' requirements.
|
Rated frequency
|
HZ | 50 60 |
| Main power | kVA | 16.2 20 |
| kW | 13 16 | |
| Standby power | kVA | 17.5 22 |
| kW | 14 17.6 | |
|
Rated voltage
|
V | 400/230 416/240 |
|
Rated current
|
A | 23.5 27.8 |
| Rated speed | r/min | 1500 1800 |
| Generator manufacturer | Faraday | |
| Generator model | FD1ES1-4（three-phase） | |
| Number of poles | 4 | |
| Excitation mode | Brushless self excitation constant voltage (with AVR) | |
| Power factor | COSΦ | 0.8(lagging) |
| Insulation class | H | |
| Engine manufacturer | YANGDONG | |
| Engine model | YND485D | |
| Structural type of cylinder block | Four cylinder in-line, four stroke, direct injection, water-cooled | |
| Cylinder bore × stroke | mm | 85×95 |
| Total displacement | L | 2.156 |
| Compression ratio | 18∶1 | |
| Rated power | KW | 17 20 |
| Cooling water volume | Engine (L) | 7 |
| Unit cooling water tank (L) | 3.7 | |
| Lubrication method | Pressure splash composite | |
| Lubricating oil model | Above CD level or SAE 10W-30, 15W-40 | |
| Lubricant capacity | L | 9.2 |
| Startup mode | 12V electric starter | |
| Starting motor capacity | V-KW | 12V 3KW |
| Charging generator capacity | V-A | |
| Battery capacity × number | V-Ah | 12V 65Ah ×1PC |
| Engine fuel consumption rate | g/KW.h | 247 247 |
| Fuel type | Diesel: 0 ＃ (summer) - 10 ＃ (winter) - 35 ＃ (cold) |
| Display model | Wisdom display | |
| Output | Socket | Two single-phase sockets |
| Terminal | Available | |
| Noise (7m) | dB(A) | |
| Unit fuel tank capacity | L | 68 |
| Fuel consumption rate (output 100% power) | L/h | |
| Fuel consumption rate (75% power output) | L/h | |
| Air inlet flow of air filter | m3/S | |
| Exhaust temperature | ℃ | |
| Muffler exhaust flow | m3/S | |
| Air intake | m3/S | |
| Overall dimensions of unit body | mm | 1500×790×1050 |
| Packaging | Plywood pallet+corrugated box | |
| Packing box size | mm | |
| Net weight of unit | kg | 630 |
