There is no need to worry about overheating as the engine has a forced air cooling system, and there is a full power panel with oil warning light, a voltmeter, circuit breaker. The DEHRAY has a super quiet muffler that reduces engine noise, so it is ideal for camping or for use in an RV.
DEHRAY RIG3500 is a powerful and versatile generator that is well made with a heavy duty steel frame. It can be used to supply emergency power to your major appliances and lights as it provides 3000 watts of starting power and up to 2800 watts for 6.7 hours of continuous power. And the reliable 4-stroke OHV single cylinder engine is easy to start with the recoil system.
There is no need to worry about overheating as the engine has a forced air cooling system, and there is a full power panel with oil warning light, a voltmeter, circuit breaker. The DEHRAY has a super quiet muffler that reduces engine noise, so it is ideal for camping or for use in an RV.
● Inexpensive
● Easy to operate with recoil system and electric system
● Relatively quiet
● Sturdy compact frame
● Ideal for powering multiple appliances
● Can be used for camping and for an RV.
● Fuel efficient
● Easy to read fuel gauge
● Oil alert lamp and voltage meter
| Rated frequency | Hz | 50 60 60 |
| Rated power | kVA | 3.5 |
| Max. power | kVA | 3.8 |
| Rated voltage | V | 230 120 240 |
| Rated current | A | 15.2 29.1 14.6 |
| Rated rotation speed | r/min | 3600 |
| DC output | / | 12V-5.0A |
| Power factor | COSΦ | 1 |
| Phase number | / | Single phase |
| Engine type | Hz | RG170F |
| Structure type | / | Single cylinder,4-stroke, air cooled,overhead valve |
| Bore×stroke | mm | 70×55 |
| Displacement | L | 0.212 |
| Compression ratio | / | 8.5:1 |
| Rated power | kW/(r/min) | 4.5/3600 |
| Lube oil brand | / | Above SF SAE 10W-30、15W-40 |
| Lube capacity | L | 0.6 |
| Ignition system | / | T.C.I |
| Spark plug | / | TORCH F7RTC |
| Starting system | / | Recoil starter,electric system |
| Battery capacity | 12V-9Ah | |
| Fuel type | / | Vehicle lead-free petrol |
| Lowest fuel consumption | g/KW.h | 395 |
| Fuel consumptiom | g/kW.h | 500 |
| Fuel tank capacity | L | 13 |
| Continuous running time(hr)(rated output) | h | 6.3 |
| Noise(unload-full load) | dB(A)/7m | 60-65 |
| Overall dimensions | mm | 645×430×520 |
| Net weight | kg | 41 |
| Structure type | / | Portable, silent |
